High Quality SMD Outdoor Stadium IP65 Waterproof 120 240 300 480 720 960 1200 1440 Watt LED Flood Light

Watt:
Efficiency:
Light Source:
Beam Angle:
Warranty:
Quantity:
  • HMA-120W/240W/300W/480W/720W/960W/1200W/1440W
  • FOCUS-LIGHTING Manufacturer

led high mast flood light


Specifications

Model HMA-120W HMA-240W HMA-300W HMA-480W HMA-720W HMA-960W HMA-1200W HMA-1440W
Watt 120W 240W 300W 480W 720W 960W 1200W 1440W
Lumen 18,600lm 37,200lm 46,500lm 74,400lm 111,600lm 148,800lm 186,000lm 223,200lm
N.W 2.5kgs 6kgs 8kgs 10kgs 13.2kgs 18kgs 21.5kgs 25kgs
LED Lumileds 5050
BeamAngle 10/20/40/60/90/140*100/135*60/30*70 degree
CCT 2700K, 3000K, 4000K, 5000K, 5700K, Red, Green, Blue
CRI Ra70, Ra80, Ra90 option
Driver MEAN WELL, SOSEN
Input Volt AC100-277V
PF >0.9
IP/IK Rate IP65/IK08
Wind Rate 51-56m/s
Certificate CE, RoHS, LVD, EMC, UL, TUV
Warranty 5-7 years

Angle adjustable PC LENS pure aluminum

Features:

> IP65 rated LED floodlight

> Rotatable modules offering maximum customisation

> Heavy duty stirrup mounting bracket

> Multiple optics available

> Can be installed as a floodlight or high bay

> Flicker-free cold start, and industry-leading 160Lm/W.

> Protractor scale for easier aiming

> 50,000-hour operating life means years of maintenancefree operation.

> Unique design extracts heat from the light source, thereby extending component life and ultimately prolonging the useful life of the fixture.

> Lightweight design provides easy retrofitting of existing HID installations,along with quick mounting on all new installations.


Electrical:
> MEAN WELL/SOSEN driver
> Power: 100W-1440W optional.
> Direct wire rang voltage AC100~277V.
> Power Factor : >0.9
> Power efficiency: >90%
> IP65, IP08

Optical:
> Top Brand Lumileds 5050 LEDs, 150-160lm/w.
> CCT 2700K-6500K optional, other color customized.
> CRI: Ra70, Ra80

> Dimmable, Non-dimmable

1440W led highmast light heat sink

Dimension

120W LED flood light240W LED flood light

300W LED flood light480W LED flood light720W LED flood light960W LED flood light

1200W LED flood light1440W LED flood light

Beam Angle

10/20/40/60/90/120/140*100 degree option

led high mast flood light beam angle

All Beam angle .ies file for DIALux

718_high mast light lighting simulation


Adjustable mount

adjustable mount


Application

Outdoor lighting, Security lighting, Industrial lighting, Sports field lighting, Construction lighting, Highmast lighting, Tunnel lighting, High mast lighting.

high mast light application
